EMC Switches 10-630A

Electromagnetic compatibility ensures safe operation in environments with electromagnetic disturbance
Tested according to EMC EN 61000-6-3:2007+A1(2011) with EMC- glands shielded power cable
IP66
Available in polycarbonate up to 125 A, aluminium up to 160 A and sheet steel up to 630 A
Padlockable
EMC cable glands included
Door interlock with defeat mechanism
Tested according to IEC 60947-3
Also available with 4, 6 or 8-poles
Note! Al-cables cannot be connected directly to switch terminals. For Al-cable connection please use a bi-metal cable connector, available here.

Technical datasheet >>

Accessories

Note: Certificates may vary between products. Check product specific certificates from the product page.

Data subject to change without notice. Always confirm the data is correct from the seller.

Inquire About This Product Group

Email*
Country*
Company
Phone number
Comments
Request a 3D drawing (.stp)
- Yes
Request a 2D drawing (.dwg)
- Yes
For which product?
Subscribe for a KATKO newsletter
- Yes
Phone
This field is for validation purposes and should be left unchanged.

Products

Type	Enclosure Material	Enclosure	Number of Poles	AC-22 400/415 V	AC-23 400/415 V	AC-23 690 V	EAN
KEM 316 M2EMC 2XM25MEMC *		M2	3	16 A	16 A / 7.5 kW	16 A / 11 kW	6419410272633
KEM 325 M2EMC 2XM25MEMC *		M2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410272787
KEM 340 M2EMC 2XM25MEMC *		M2	3	40 A	40 A / 22 kW	25 A / 22 kW	6419410275696
KEA 316 A2EMC 2XM25MEMC KST16M *		A2	3	16 A	16 A / 7.5 kW	16 A / 11 kW	6419410282199
KEA 325 A2EMC 2XM25MEMC KST16M *		A2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410279861
KEA 340 A2EMC 2XM25MEMC KST16M *		A2	3	40 A	40 A / 22 kW	25 A / 22 kW	6419410277249
KEM 316 YR M2EMC 2XM25MEMC *		M2	3	16 A	16 A / 7.5 kW	16 A / 11 kW	6419410276747
KEM 325 YR M2EMC 2XM25MEMC *		M2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410276754
KEM 340 YR M2EMC 2XM25MEMC *		M2	3	40 A	40 A / 22 kW	25 A / 22 kW	6419410275702
KEA 316 YR A2EMC 2XM25MEMC KST16M *		A2	3	16 A	16 A / 7.5 kW	16 A / 11 kW	6419410274255
KEA 325 YR A2EMC 2XM25MEMC KST16M *		A2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410274323
KEA 340 YR A2EMC 2XM25MEMC KST16M *		A2	3	40 A	40 A / 22 kW	25 A / 22 kW	6419410277256
KER 316 YR RA2EMC 2XM25MEMC KST16M *		RA2	3	16 A	16 A / 7.5 kW	16 A / 11 kW	6419410274965
KER 325 YR RA2EMC 2XM25MEMC KST16M *		RA2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410275009
KER 340 YR RA2EMC 2XM25MEMC KST16M *		RA2	3	40 A	40 A / 22 kW	25 A / 22 kW	6419410277270
KER 325 YR RA2EMC 2XM25MEMC KST16M	AISI316	RA2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410484210
KER 340 YR RA2EMC 2XM25MEMC KST16M	AISI316	RA2	3	40 A	40 A / 22 kW	32 A / 30 kW	6419410484227
KER 363 YR RA4EMC 2XM40MEMC KST16M	AISI316	RA4	3	63 A	40 A / 22 kW	40 A / 37 kW	6419410484234
KER 380 YR RA4EMC 2XM40MEMC KST16M	AISI316	RA4	3	80 A	63 A / 30 kW	40 A / 37 kW	6419410484241
KER 3125 YR RA4EMC 2XM40MEMC KST16M	AISI316	RA4	3	125 A	125 A / 55 kW	80 A / 75 kW	6419410484265
KER 3160 YR RA5EMC 2XM50MEMC	AISI316	RA5	3	160 A	160 A / 90 kW	100 A / 90 kW	6419410484272
KER 3200 YR R6EMC 2XM50MEMC	AISI316	R6	3	200 A	200 A / 110 kW	200 A / 160 kW	6419410342404
KER 316 YR RA2EMC 2XM25MEMC KST16M	AISI316	RA2	3	16 A A	16 A / 7,5 kW	16 A / 11 kW	6419410484203
KEM 316 M2EMC 2XM25MEMC	Polycarbonate	M2	3	16 A	16 A / 7.5 kW	16 A / 11 kW	6419410329207
KEM 325 M2EMC 2XM25MEMC	Polycarbonate	M2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410329214
KEM 340 M2EMC 2XM25MEMC	Polycarbonate	M2	3	40 A	40 A / 22 kW	32 A / 30 kW	6419410329221
KEM 363 M3EMC 2XM32MEMC	Polycarbonate	M3	3	63 A	40 A / 22 kW	40 A / 37 kW	6419410329238
KEM 380 M3EMC 2XM32MEMC	Polycarbonate	M3	3	80 A	63 A / 30 kW	40 A / 37 kW	6419410329245
KEM 3100 M4EMC 2XM40MEMC	Polycarbonate	M4	3	100 A	100 A / 55 kW	63 A / 55 kW	6419410315484
KEM 3125 M4EMC 2XM40MEMC	Polycarbonate	M4	3	125 A	125 A / 55 kW	80 A / 75 kW	6419410315491
KEA 316 A2EMC 2XM25MEMC KST16M	Aluminium	A2	3	16 A	16 A / 7.5 kW	16 A / 11 kW	6419410483008
KEA 325 A2EMC 2XM25MEMC KST16M	Aluminium	A2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410483015
KEA 340 A2EMC 2XM25MEMC KST16M	Aluminium	A2	3	40 A	40 A / 22 kW	32 A / 30 kW	6419410483022
KEA 363 A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	63 A	40 A / 22 kW	40 A / 37 kW	6419410336601
KEA 380 A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	80 A	63 A / 30 kW	40 A / 37 kW	6419410336618
KEA 3100 A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	100 A	100 A / 55 kW	63 A / 55 kW	6419410315507
KEA 3125 A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	125 A	125 A / 55 kW	80 A / 75 kW	6419410336625
KEA 3160 A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	160 A	160 A / 90 kW	100 A / 90 kW	6419410315514
KET 3160 T5EMC 2XM50MEMC	Sheet Steel	T5	3	160 A	160 A / 90 kW	100 A / 90 kW	6419410336649
KET 3200 T6EMC 2XM50MEMC	Sheet Steel	T6	3	200 A	200 A / 110 kW	200 A / 160 kW	6419410336656
KET 3250 T6EMC 2XM63MEMC	Sheet Steel	T6	3	250 A	250 A / 132 kW	250 A / 250 kW	6419410336663
KET 3315 T6EMC 2XM63MEMC	Sheet Steel	T6	3	315 A	315 A / 160 kW	315 A / 315 kW	6419410336670
KET 3400 T7EMC 2XM63MEMC	Sheet Steel	T7	3	400 A	400 A / 200 kW	400 A / 355 kW	6419410336687
KET 3630 T7EMC 2XM63LMEMC	Sheet Steel	T7	3	630 A	630 A / 355 kW	630 A / 630 kW	6419410336694
KEM 316 YR M2EMC 2XM25MEMC	Polycarbonate	M2	3	16 A	16 A / 7.5 kW	16 A / 11 kW	6419410329252
KEM 325 YR M2EMC 2XM25MEMC	Polycarbonate	M2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410329269
KEM 340 YR M2EMC 2XM25MEMC	Polycarbonate	M2	3	40 A	40 A / 22 kW	32 A / 30 kW	6419410329276
KEM 363 YR M3EMC 2XM32MEMC	Polycarbonate	M3	3	63 A	40 A / 22 kW	40 A / 37 kW	6419410329283
KEM 380 YR M3EMC 2XM32MEMC	Polycarbonate	M3	3	80 A	63 A / 30 kW	40 A / 37 kW	6419410329290
KEM 3100 YR M4EMC 2XM40MEMC	Polycarbonate	M4	3	100 A	100 A / 55 kW	63 A / 55 kW	6419410315521
KEM 3125 YR M4EMC 2XM40MEMC	Polycarbonate	M4	3	125 A	125 A / 55 kW	80 A / 75 kW	6419410315538
KEA 316 YR A2EMC 2XM25MEMC KST16M	Aluminium	A2	3	16 A	16 A / 7.5 kW	16 A / 11 kW	6419410483039
KEA 325 YR A2EMC 2XM25MEMC KST16M	Aluminium	A2	3	25 A	25 A / 11 kW	25 A / 22 kW	6419410483046
KEA 340 YR A2EMC 2XM25MEMC KST16M	Aluminium	A2	3	40 A	40 A / 22 kW	32 A / 30 kW	6419410483053
KEA 363 YR A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	63 A	40 A / 22 kW	40 A / 37 kW	6419410336465
KEA 380 YR A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	80 A	63 A / 30 kW	40 A / 37 kW	6419410336472
KEA 3100 YR A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	100 A	100 A / 55 kW	63 A / 55 kW	6419410315545
KEA 3125 YR A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	125 A	125 A / 55 kW	80 A / 75 kW	6419410336489
KEA 3160 YR A4EMC 2XM40MEMC KST16M	Aluminium	A4	3	160 A	160 A / 90 kW	100 A / 90 kW	6419410315552
KET 3160 YR T5EMC 2XM50MEMC	Sheet Steel	T5	3	160 A	160 A / 90 kW	100 A / 90 kW	6419410338735
KET 3200 YR T6EMC 2XM50MEMC	Sheet Steel	T6	3	200 A	200 A / 110 kW	200 A / 160 kW	6419410338742
KET 3250 YR T6EMC 2XM63MEMC	Sheet Steel	T6	3	250 A	250 A / 132 kW	250 A / 250 kW	6419410338759
KET 3315 YR T6EMC 2XM63MEMC	Sheet Steel	T6	3	315 A	315 A / 160 kW	315 A / 315 kW	6419410338766
KET 3400 YR T7EMC 2XM63MEMC	Sheet Steel	T7	3	400 A	400 A / 200 kW	400 A / 355 kW	6419410338773
KET 3630 YR T7EMC 2XM63LMEMC	Sheet Steel	T7	3	630 A	630 A / 355 kW	630 A / 630 kW	6419410338780
