Dane mogą ulec zmianie bez powiadomienia. Zawsze potwierdź dane u swojego sprzedawcy.
General use rating 60 – 100 A / 600VAC, refer to detailed product specifications
Lockable to off-position
Switching speed is independent of the operator
Silver contacts ensure safe and durable operation
Suitable for use on a circuit capable of delivering 50kA rms symmetrical, 600 Vac when protected by Class J, 60A/100A fuse.
Change-over switches consist of two 3- or 4-pole switches. Marked with CO.
Note! Auxiliary contacts 160KU1V, 160KU2V, 160KU1VAU and 160KU2VAU used with 4 pole and 8 pole KU 100-160A (IEC) and KU 60-100A (UL98) might have less than 20ms time interval between the opening of the contacts of the auxiliary switch and the contacts of the main poles.
Prąd znamionowy (600V)
Rozmiar przewodu (Tylko Cu)
1,3 / 0,45
