KEM 3125C VV

Change-over switches 16-160A

  • Polycarbonate (TKM, KEM) or aluminium (KEA) enclosures
  • TKM-models with cam switch 16 to 40 A
  • KEM and KEA models consist of two KU or VKA switches connected by a change-over kit and range from 16 to 160 A
  • IP66; enclosure types U2, U3, A2
  • IP65; enclosure type MF11
  • Self-extinguishing material
  • Excellent insulating properties
  • Wide operating temperature range
  • Good resistance against many chemicals
  • Good UV resistance
  • Padlockable with three locks
  • Door interlock with defeat mechanism
  • Tested according to IEC 60947-3

Technical datasheet>>

Product details

SKU KEM 3125C VV
AC-21 400/415 V (A) 125 A
AC-21 690 V (A) 125 A
AC-22 400/415 V (A) 125 A
AC-22 690 V (A) 80 A
AC-23 400/415 V (A/kW) 63 A / 30 kW
AC-23 690 V (A/kW) 40 A / 37 kW
Cable Area to Switch Terminal (mm2) / Bolt size 6-70
Color Standard
EAN 6419410320686
Enclosure MF11
Enclosure Type Polycarbonate
IP Rating 65
Number of Poles 3
Operation Front-operated
Switch type Change-over Switch
Weight (kg) 2.1
