KVKET 3125 T6

Enclosed switch fuse 3x125A DIN 000/00

KVKET 3125 T6

Katko FuseSafe enclosed switch fuses combine reliable switching and fuse protection in a safe and space-saving solution for professional electrical installations. Available in polycarbonate, steel, and stainless steel enclosures, FuseSafe is suitable for a wide range of industrial, building, and infrastructure applications. Durable enclosure materials ensure reliable performance in both standard indoor installations and demanding industrial environments.

Rated operational current AC-22A 415V (A)
125
Rated operational current AC-22A 690V (A)
125
Enclosure
T6 (400 x 600 x 200 mm)
Enclosure type
Painted sheet steel

Looking for more information about this product?

Our team is here to help.

 View full details

Product details and documents

Technical data

Depth
200 mm
Enclosure
T6 (400 x 600 x 200 mm)
Enclosure type
Painted sheet steel
ETIM Class
EC001040
Fuse type DIN
000/00
GTIN
6419410395356
Height
600 mm
Max. term. torque (Nm)
6
Mech. endurance (no. of oper.)
20000
Net weight
16.5498 kg
Nom. values w/cable size (mm²)
50
Number of poles
3
Product type
KVKET 3125 T6
Rated breaking cap. ICN AC-23A 415V (A)
1000
Rated breaking cap. ICN AC-23A 500V (A)
1000
Rated breaking cap. ICN AC-23A 690V (A)
1000
Rated fused short-ckt current back-up fuse opt 1 (A)
125
Rated fused short-ckt current RMS Ik opt 1 (kA)
50
Rated fused short-ckt. impulse withstand volt. Uimp (kV)
8
Rated insulation volt. Ui (V)
690
Rated operational current AC-21A 415V (A)
125
Rated operational current AC-21A 500V (A)
125
Rated operational current AC-21A 690V (A)
125
Rated operational current AC-22A 415V (A)
125
Rated operational current AC-22A 500V (A)
125
Rated operational current AC-22A 690V (A)
125
Rated operational current AC-23A 415V (A)
125
Rated operational current AC-23A 500V (A)
125
Rated operational current AC-23A 690V (A)
125
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 415V (kW)
55
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 500V (kW)
75
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 690V (kW)
110
Rated short-ckt. making cap. Icm 690V (kA)
6
Rated short-time withstand current 1s Icw 690V (kA)
4
Rated therm. current Ithe (A)
125
Rated therm. current Ith (A)
125
Short product description
Enclosed switch fuse 3x125A DIN 000/00
Switch type
Switch Fuse
Terminals bolt size (Cu mm²)
6..70
Volume
48 l
Width
400 mm

Dimensional drawing

Logistical data

Package size 1
1
Package size 1 depth
200 mm
Package size 1 GTIN code
6419410395356
Package size 1 height
600 mm
Package size 1 volume
48 l
Package size 1 weight
16.5498 kg
Package size 1 width
400 mm
Sales unit
1
