KU 380N

UL Listed KU Series 16-80A

  • Rotary switch with extended handle
  • UL 60947-4-1A
  • CCA, CB certificates
  • ISO 9001
  • Compact size
  • DIN-rail mounting
  • Switch technology by means of silver contacts ensures safe and durable operation
  • Compatible with handles LK10UL and LK11UL
  • Shafts L=100/200/300 AD11 and L=100/200/300 AD11/VT

Product details

SKU KU 380N
Ampere Rating (600V) 80 A
EAN 6419410214701
HP 208V 10HP
HP 480V 30HP
HP 600V 30HP
Number of Poles 3
Operation Rotary
Weight (lb/kg) 0.418 / 0.19
Wire Size (Cu Only) 12-4 AWG

Dimensional drawing

Product diagram
