KER 4630 RA7BVS
KER Stainless steel visual isolating 200-800 A
- IP66; AISI 316 Enclosure types RA6AVS, RA7AVS, RA7BVS, RA10VS
- Where hygiene and good protection against corrosion are required
- Visual isolating: visual status indication window in enclosure
- Padlockable with three locks
- Door interlock with defeat mechanism
- Tested according to IEC 60947-3
- 6 and 8-pole versions available
- Note! Al-cables cannot be connected directly to switch terminals. For Al-cable connection please use a bi-metal cable connector, available here.
|SKU||KER 4630 RA7BVS|
|AC-21 400/415 V (A)||630 A|
|AC-21 690 V (A)||630 A|
|AC-22 400/415 V (A)||630 A|
|AC-22 690 V (A)||630 A|
|AC-23 400/415 V (A/kW)||630 A / 355 kW|
|AC-23 690 V (A/kW)||630 A / 630 kW|
|Enclosure Type||Stainless Steel with visual indication|
|Number of Poles||4|
|Switch type||Load Break Switch|
