ISF 440UL YR A2

Manual motor controller 4x40A

ISF 440UL YR A2

Katko UL/cUL listed aluminium enclosed disconnect switches are designed for demanding industrial and commercial applications where safety, compliance and reliable disconnection are essential. Featuring a Type 4 aluminium enclosure, they provide strong mechanical protection, good corrosion resistance and efficient heat dissipation, ensuring dependable operation in both indoor and outdoor environments.

The switches support across-the-line motor starting up to 75 HP at 600 V and are suitable for a wide range of motor and load disconnect applications. Certified according to UL and CSA requirements and compliant with UL 60947-4-1A, they meet the expectations of North American installations where performance and regulatory compliance are critical. Developed using Katko’s application-driven engineering approach, these disconnect switches deliver long-term reliability and safe electrical distribution wherever durability and proven standards matter.

E-number FI
GTIN
6419410294611
Ampere rating 600V
40
Enclosure type
Aluminium
Enclosure
A2 (104 x 159 x 80 mm)

Looking for more information about this product?

Our team is here to help.

View full details

Product details and documents

Technical data

Ampere rating 600V
40.0
Depth
114 mm
EMC
false
Enclosure
A2 (104 x 159 x 80 mm)
Enclosure type
Aluminium
ETIM Class
EC000216
E-number FI
3662536
GTIN
6419410294611
Height
159 mm
HP 208V
5.0
HP 480V
15.0
HP 600V
20.0
IP rating
IP66
Long product name
UL-listed, 4-pole, Yellow-red handle, Aluminum enclosure; W104 x H158.5 x D79.5
Number of poles
4
Product type
ISF 440UL YR A2
Short product description
Manual motor controller 4x40A
Technical name
4x40A 400V 22kW
UL
UL 60947-4-1A
Volume
1.8851 l
Width
104 mm
Wire size Cu
14-8 AWG

Dimensional drawing

Logistical data

Package size 1 depth
108 mm
Package size 1 GTIN code
6419410294611
Package size 1 height
262 mm
Package size 1 volume
4.584 l
Package size 1 width
162 mm
