Katko LoadSafe EVA toggle load break switches (200–250A) are robust and compact solutions designed for reliable load switching in medium-capacity electrical systems. Available in 3- and 4-pole versions with options for terminal covers and phase barriers, these switches support flexible installation requirements while maintaining straightforward operation.
Switch technology based on silver contacts ensures safe, durable operation even in demanding environments, and devices are tested according to IEC 60947-3 for consistent performance.
Technical data
Depth
106 mm
ETIM Class
EC000216
E-number FI
3609255
GTIN
6419410203187
Height
77 mm
Long product name
Toggle switch, 3-pole, 2 x Terminal covers,4 x Phase barriers, Red toggle
Max. term. torque (Nm)
15..22
Mech. endurance (no. of oper.)
16000
Nom. values w/cable size (mm²)
95
Number of poles
3
Product type
EVA 3200 R 2XLS4XVS
Rated breaking cap. ICN AC-23A 415V (A)
1280
Rated fused short-ckt current back-up fuse opt 1 (A)
250
Rated fused short-ckt current peak value (kA)
21
Rated fused short-ckt current RMS Ik opt 1 (kA)
50
Rated fused short-ckt. impulse withstand volt. Uimp (kV)
6
Rated insulation volt. Ui (V)
690
Rated operational current AC-21A 415V (A)
200
Rated operational current AC-22A 415V (A)
200
Rated operational current AC-23A 415V (A)
160
Rated oper. power 3-ph 1500rpm SQ cage motor AC-23A 415V (kW)
75
Rated short-ckt. making cap. Icm 415V (kA)
11.4
Rated short-time withstand current 1s Icw 415V (kA)
6.5
Rated therm. current Ith (A)
200
Short product description
Toggle switch 3x200A
Switch type
Load Break Switch
Technical name
3x160A 400V 75kW
Terminals bolt size (Cu mm²)
M8
Volume
1.51 l
Width
185 mm
Dimensional drawing
Logistical data
Package size 1
1
Package size 1 depth
106 mm
Package size 1 GTIN code
6419410203187
Package size 1 height
77 mm
Package size 1 volume
0.8652 l
Package size 1 width
106 mm
Sales unit
1
Downloadables
- Dimensional drawings media (LoadSafe_EVA_3P_4P_200_250_VS_LS.png)
- Connection diagram media (KATKO_KU3P_diagram)
- Brochures (Katko LoadSafe Catalogue - Load Break and Change-Over Switches EN)
- Brochures (Katko LoadSafe Tuoteluettelo - Kuormankytkimet ja vaihtokytkimet FI)
- STEP files (LoadSafe_EVA_3P_200_250_2XLS4XVS.zip)
